- Most trailer winch mount ideas skip the only question that matters: what the mount has to hold, and from which direction.
- Front of the trailer, tied into the frame rails, pulling straight down the deck. Not the stake pocket. Not the plywood.
- A 4,000 lb winch puts 4,000 lb into its bolts on the first layer of rope.[1]
- Pull in line or don't pull. "Do not apply side loads to your recovery points."[2]
- The no-mount option is real: the Trojan works loose out of its case, and has an 8.3 × 9.2 in mounting pattern for when you want it bolted down.[1]
- Murphy's sells no mounting hardware. That part comes from a fabricator.
1. One man, one tank, no crane
The tank is full-size, it's going up into the bed of a truck, and there's nobody there to help lift it. Rick's on his own with a Facebook Marketplace find that's been sitting fifteen years, and he's decided to swap the diesel tank out rather than clean it and change filters the whole way home. Sensible. Except now there's a tank to move.
"Now, granted, I can get the tank up in the back of the truck. I do have my little Warrior winch in the box, so might have to make something work."Wrecker Rick, 41:24, "I Bought My Dream Truck On Facebook Marketplace…Or A Nightmare?"
Watch what he reaches for. Not a mounted winch on a bumper. A winch in a box, that goes wherever the job is. That's the argument this whole article is about to have with itself.
2. Where a winch goes on a trailer
Front of the trailer. Pulling straight down the deck. Right about 90% of the time.
Three places people actually put them, in order of how well they hold up:
- On the A-frame, ahead of the deck. The strongest structure on most trailers, and the line runs straight down the middle. Usually a short plate across the two frame members.
- On a deck plate at the front, tied into both frame rails. Keeps the winch low and clear of the coupler. The plate has to reach the rails. Bolting into deck boards is how mounts get ripped out.
- On a removable bracket in a receiver tube. Handy. It can only pull as straight as the tube points, and any side load goes into that tube as a twist.
Where a winch does not go: a stake pocket, a side rail, or a deck board. Not because it won't bolt up, but because the load has nowhere to go but into thin steel or timber.
3. What the mount actually holds
A winch mount carries the winch's full first-layer rated pull. Not the weight of what you're dragging. The line pull, which is the number on the winch.
Warrior's published layer table for the Trojan starts at 4,000 lb with 8.5 ft of rope out, dropping to 2,530 lb once all 49 ft is on the drum.[1] So the mount has to be good for 4,000 lb, even though the winch only makes that on the first layer. Size for the worst case.
Three things that mount has to do:
- React the pull into structure. A plate that spreads the load across the frame rails, not a bracket hanging off one edge of it.
- Hold the fairlead too. The fairlead takes whatever the line pushes into it when the pull isn't straight, and that's a sideways load on the same bolts.
- Stay in line. BFGoodrich's rule is flat: "Do not apply side loads to your recovery points, always pull in line."[2] That's the mount as much as the recovery point at the other end.
And one place a winch never gets anchored, at either end. BFGoodrich again: "Do not attach a strap to a tow ball or bumper hitch. These are not rated for recovery and can break off under load."[2] A recovery point built for a receiver is a different thing, and the 2" one is rated to a 13,200 lb working load limit at 5:1, in line with the hitch only.
4. Bolt-on mount or a winch you carry
| Bolted to the trailer | Portable, in a box | |
|---|---|---|
| Where it can pull from | One place, one direction | Wherever you can anchor it |
| Setup time per job | None, it's already there | A few minutes to place and clip up |
| What you have to build | Plate, hardware, wiring | Nothing |
| Works on more than one trailer | No | Any trailer, any truck |
| Capacity you can buy | Up to 10,000 lb and beyond | 4,000 lb first layer, 2,530 lb spooled out[1] |
The Trojan doesn't force the choice, which is the part that gets missed. Warrior's own copy says it requires no mounting or setup, and that it can be securely mounted to a trailer or worksite for everyday use. There's an 8.3 × 9.2 inch mounting pattern on the spec sheet and a quarter-inch steel plate under it.[1] Run it loose for a year, then bolt it down when you're ready.
"And I know what you're thinking. Wrecker Rick, you got the wrong tool for the job. No, you're wrong. I got the right tool for the job."Wrecker Rick, 41:56, same episode
He says that about the pliers in his hand, not about a winch. Same argument though.
4,000 lb on the first layer, 49 ft of synthetic rope, 42 lb, in a carry case with a quick-connect cord and clips. Works loose, or bolts down on an 8.3 × 9.2 in pattern when you want it permanent. Mounting hardware is not included and Murphy's does not sell it.
The one that works either way. 8.3 × 9.2 in mounting pattern, quarter-inch steel plate, 42 lb to carry.
For a trailer that loads equipment every week. 10,000 lb of line pull, synthetic rope, aviation-grade aluminium fairlead and hook. Needs a plate and wiring you supply.
Shields synthetic line from trees, rocks and the bumper face. Standard 10 in bolt spacing on full-size models. Its own page says it plainly: hardware is not included.
A rated point at the tow-vehicle end. 13,200 lb working load limit at 5:1. In line with the hitch only, never a side pull. Receiver pin not included.
5. Where the no-mount option stops working
Honest limits, because a portable winch is not a mounted winch wearing a disguise.
A loose winch has to be restrained by something while it pulls, and that something is on you to arrange. Bolted down, the trailer takes the load. Loose, whatever you hooked the platform to takes it, and that connection is now the weakest part of the setup.
It's also slower. Every job starts with placing it, clipping it to a battery and anchoring the back of it. Fine once. Twice a day, five days a week, you'll want it bolted down and wired in.
And it's 4,000 lb, dropping to 2,530 lb once the rope's spooled on.[1] If you're winching dead machinery up a deck regularly, that's a 10,000 lb winch's job, not this one's.
6. What Murphy's doesn't sell
Mounting hardware. Any of it. No trailer plate, no bumper mount, no bracket, no bolt kit. An article about mounts that quietly sold you one would be better for the store and worse for you, so the line gets drawn properly.
Even the Groove Fairlead, the closest thing in the catalogue to a mounting part, says it on its own page: hardware is not included.
What Murphy's sells is the winch that needs no mount, the winch you'd bolt to a plate, the fairlead that protects the rope, and the rated point at the other end. The plate and the bolts come from a fabricator, and it's worth having someone who welds for a living look at where you're putting it.
7. Before you pull on anything
Quoted from a non-competitor recovery source, plus the ratings on the gear itself.
- Pull in line. "Do not apply side loads to your recovery points, always pull in line with the vehicle." A side pull loads a mount in the one direction nobody sized it for.[2]
- Never off a tow ball. "Do not attach a strap to a tow ball or bumper hitch. These are not rated for recovery and can break off under load."[2]
- Gloves on. "Do not winch without gloves."[2]
- Dampener on the line. "Do not winch without a line dampener in place."[2]
- Nobody between the winch and the load. "Do not stand next to or straddle the winch cable."[2]
- Chock the trailer and hitch it first. A winch pulling up a deck can walk an unhitched trailer.
- Check the mount. Bolts back off. Welds crack. Look before you load, not after.
Source: [2] BFGoodrich, 4x4 Driving Guide: Recovery Techniques
8. The bottom line
Front of the trailer, tied into the frame, pulling straight down the deck, built for the winch's full rated pull rather than the load you think you'll drag. That's every good trailer winch mount. The rest is detail.
Then ask whether you need a mount at all. A man on his own with a tank to lift reached into the bed for a winch in a box, because it goes where the work is instead of waiting for the work to come to it.
Bolt it down when the job repeats. Carry it when it doesn't.
Sources
- Warrior Winches, published specification sheet, Trojan 4,000 lb 12v portable utility winch. "Mounting Pattern 8.3 × 9.2 in"; "Weight 42 lbs"; "Cable Size (Diameter x Length) 0.20 in x 49 ft"; layer table 4,000 / 3,351 / 2,883 / 2,530 lb; "Durable Hardened Steel Plate: Built with 1/4-inch thick steel"; "This winch requires no mounting or setup"; "It can also be securely mounted to a trailer or worksite for dependable, everyday use." Listed under Application: Trailers. Fetched 2026-09-19. warriorwinches.com/products/warrior-portable-4000-trojan-winch
- BFGoodrich, "4x4 Driving Guide: Recovery Techniques." "DO NOT put side loads on recovery points, always pull in line with the vehicle." "DO NOT attach a strap to a tow ball or bumper hitch. These are not rated for recovery and can break off under load." "Do not winch without gloves." "Do not winch without a line dampener in place." "Do not stand next to or straddle the winch cable." "A good safety rule is to stand farther back than the full length of the winch line." Fetched 2026-09-19. bfgoodrichtires.com/auto/learn/4x4-driving-guide/recovery-techniques
Prices and stock confirmed against the live Murphy's Diesel storefront on September 19, 2026.
